Excavator Piling Equipment for 20-85ton excavator - Long Reach Hydraulic Piling Arm for Deep Foundation Drilling
Product Description-----Excavator Pile driving Boom Arm
What is an excavator piling arm?
An Excavator Pile Driving Arm is a specialized hydraulic attachment for excavators, enabling them to install piles deep into the soil. This tool is crucial for creating reliable foundations in a variety of construction projects.
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Advantages of excavator piling arm:
1. The design improvements include thicker upper and lower plates and double internal reinforcement, which contribute to the piling arm’s overall durability. Segmented thickened plates at stress points also increase its lifespan.
Some common size references
|
Excavator
(ton)
|
Total Length
(mm)
|
Boom
(mm)
|
Arm(mm) |
Pilling Height (mm) |
Counterweight
(ton)
|
| 30-36 | 13800 | 10000 | 3800 | 15400 | 3T |
| 30-36 | 15000 | 10500 | 4500 | 17100 | 5T |
| 40-45 | 15800 | 11000 | 4800 | 17900 | 3T |
| 40-45 | 16800 | 11500 | 5300 | 18500 | 5T-6T |
| 45-50 | 19000 | 12500 | 6500 | 21000 | 6T-7T |
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product Detail Display
Excavator Pile Driving Arm: Suitable Working Conditions
About Hydraulic Vibratory Pile Driving Hammer
1. Part of engineering applications:
Municipal sewage pipeline laying, land reclamation, bridge cofferdam, building foundation, high-speed railway foundation treatment, highway soft foundation treatment, wharf engineering, deep foundation pit support, etc.
2. Hydraulic vibratory hammer consists of four main components:
Boom assembly, frame assembly, housing assembly and fixture assembly.
It is mainly used for piling, such as driving reinforced concrete piles and steel sheet U-piles into the ground to reinforce the foundation, and then supporting the structure or fixing the building.
High precision machine of Zhonghe Machinery Manufacturers
Large Floor-Standing Double-Sided Boring and Milling Lathe:
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
About Zhonghe Machinery Company Profile:
Kaiping Zhonghe Machinery Manufacturing Co., Ltd.
Kaiping Zhonghe Machinery Manufacturing Co., Ltd. was established in 2018, focusing on production and trade. Our expertise lies in customizing excavator booms and attachments, including telescopic and demolition arms, with sales in over 60 regions.
Our strengths include:
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
CE certification & Utility model patent certificates
Our products have been exported to over 60 countries, utilizing various transportation methods such as sea, land, and air freight. For packaging, we use either wooden crates or stretch film to secure the products. Before shipment, the goods are carefully packaged and then loaded into containers to ensure their safety during transit.
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Packaging & Shipping
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
FAQ(Some frequently asked questions):
Q: Are you a manufacturer?
A: Zhonghe machinery offered a wide range of attachment parts for excavators and dozers. Such as long reach arm, demolition arm, telescopic arm, standard bucket, rock bucket, cleaning bucket, tilting bucket, etc. We know that the perfect combination of high-quality cast steel products and a moderate price is the key to the success.
Q: What material is the excavator pile driving boom arm made of?
A: Shaogang Q355B, Shaogang's material has the advantages of good toughness, high welding performance, and not easy to crack. Q355B has good welding performance and can be processed at room temperature. The standard arm material of the host manufacturer is also Q355B, which is easier to purchase on the market and the subsequent maintenance cost is also simple. If the customer's working conditions are bad, we will also use Q690 material, the long arm will be made lighter and more efficient
Q: Why choose Zhonghe over other companies?
A: We offer a highly skilled production and design team that delivers high-quality, customized solutions tailored to each customer’s needs. Our commitment to precision and customer service has earned us a strong reputation in China, with annual sales consistently ranking among the top in the industry.
Q: What are your terms of payment?
A: We prefer T/T (50/50) payment terms, and for trial orders, we recommend using Ali Credit Insurance for added security.
